Name: Highways

Display Field: ABBR_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="margin:0 0 7 0;"><SPAN STYLE="font-size:12pt">S:\DataGDB\Basemap\basemap.gdb</SPAN><SPAN STYLE="font-size:14pt">\</SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Taken from the MNR Roads Layer. </SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>This layer was derived from the MNR Layer and Highways alone were exported to it's own layer. </SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN /><SPAN /></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Alleyway/Laneway: Allow speed thoroughfare dedicated to provide access to the rear of properties.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Arterial: A major thoroughfare with medium to large traffic capacity</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Collector: A minor thoroughfare mainly used to access properties and to feed traffic with right of way.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Expressway/Highway: A high speed thoroughfare with a combination of controlled access and intersections at grade level.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Freeway: An unimpeded, high speed controlled access thoroughfare for through traffic with typically no at grade intersections, usually with no property access or direct access and which is accessed by a ramp. Pedestrians prohibited.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Local/Strata: A low speed thorough fare dedicated to provide access to properties with potential public restriction, trailer parks, First Nations, strata or private states.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Local / Street: A low speed thoroughfare dedicated to provide full access to the front of properties.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Local/Unknown: A low speed thoroughfare dedicated to provide access to the front of properties but for which the access regulations are unknown.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Ramp: A system of interconnecting roadways providing for the controlled movement between two or more roadways.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Rapid Transit: A thoroughfare restricted 24 hours a day, for the sole use of public transportation buses.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Resource/Recreation: Access for resources extraction and also may have a role in providing an access for the public to back country.</SPAN></SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN><SPAN>Service: As stretch of road permitting vehicles to come to a stop along a Freeway or Highway. These include weigh scales, emergency lanes, lookouts and rest areas.</SPAN></SPAN></P><P STYLE="margin:8 0 0 0;"><SPAN /></P></DIV></DIV></DIV>

Service Item Id: 582202eb7a13464ba1a3af2c19546172

Copyright Text: MNR LIO.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8919660.400593815
YMin: 5352717.016295359
XMax: -8725289.900962796
YMax: 5509420.296414831
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [78, 78, 78, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: middle
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 6
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ABBR_NAME ( type: esriFieldTypeString, alias: ABBR_NAME, length: 100 )
• NAME_BODY ( type: esriFieldTypeString, alias: NAME_BODY, length: 50 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
